Description: Operational Amplifiers - Op Amps Dual
Operating Supply Current :: |
5 mA |
Ib - Input Bias Current :: |
300 nA |
Mounting Style :: |
SMD/SMT |
Minimum Operating Temperature :: |
- 40 C |
SR - Slew Rate :: |
4 V/us |
Supply Voltage - Max :: |
14 V |
Package / Case :: |
DMP-8 |
Maximum Operating Temperature :: |
+ 85 C |
Supply Voltage - Min :: |
2 V |
Product Category :: |
Operational Amplifiers - Op Amps |
Series :: |
NJM2115 |
GBP - Gain Bandwidth Product :: |
12 MHz |
Number of Channels :: |
2 Channel |
Vos - Input Offset Voltage :: |
6 mV |
Manufacturer :: |
NJR |
Shutdown :: |
No Shutdown |
CMRR - Common Mode Rejection Ratio :: |
60 dB |
Operating Supply Current :: |
5 mA |
Ib - Input Bias Current :: |
300 nA |
Mounting Style :: |
SMD/SMT |
Minimum Operating Temperature :: |
- 40 C |
SR - Slew Rate :: |
4 V/us |
Supply Voltage - Max :: |
14 V |
Package / Case :: |
DMP-8 |
Maximum Operating Temperature :: |
+ 85 C |
Supply Voltage - Min :: |
2 V |
Product Category :: |
Operational Amplifiers - Op Amps |
Series :: |
NJM2115 |
GBP - Gain Bandwidth Product :: |
12 MHz |
Number of Channels :: |
2 Channel |
Vos - Input Offset Voltage :: |
6 mV |
Manufacturer :: |
NJR |
Shutdown :: |
No Shutdown |
CMRR - Common Mode Rejection Ratio :: |
60 dB |
